Manganese Oxide
Manganese Oxide
Manganese Oxide is a weight material for use in drilling, completion & cementing fluids. It comprises micro spherical particles of manganese tetroxide, which enable fluids of high density with low ECD, minimal sag & formation damage mitigation.
Applications
- For low rheology fluids
- For tight ECD management requirements < 0.5 ppg
- For tight sag control requirements < 0.505 static sag
- Ready to use kill fluids, completion fluids, packer fluids
- To extend the density window for brines such as formats
- To mitigate formation damage
- Temperatures > 1500c
- For high density fluids to 3.0 sg (25 ppb)
- In completion & packer fluids
- Specific gravity: 4.7-4.9
- Mn content: 65-70%
- Fe content: 4.5% max
- Surface area: 1-4 m2/g
- Average particle size: >5μm
- Surface area: 2 m2/g
- Bulk density: 950-1050 kg/m3 (when packed)
- 1MT big bags
- 25 kg bags
